Noise Reduction in Glucose Sensors

Biometric measurement device that uses an implantable device inserted into the body of a subject to measure biometric parameters like glucose levels. The implant device emits an electromagnetic signal at a specific frequency to penetrate the tissue and measure the reflected signal from the analyte in the interstitial fluid. An external device provides power to the implant and receives the measured data. This allows long-term implantable biometric monitoring without invasive blood sampling. The implant device has features like aligned external sensors, RF shielding, and switching between sensing and power reception to reduce interference.

Source

High speed non-invasive sensor for measuring blood glucose levels without piercing the skin. The sensor uses a technique called high speed spectral sweep analysis to collect large amounts of spectral data by rapidly varying the emitter wavelength. This allows accurate determination of glucose levels. The sensor also controls and compensates for factors like emitter temperature, tissue temperature, and detector temperature to reduce distortion in the collected spectral data. By carefully managing the environmental conditions during measurement, it enables more accurate glucose prediction from the spectral sweep.

Source

Accurately calibrating biometric signals from a continuous monitoring device like a glucose sensor in a way that compensates for instability in the sensor's performance over time. The method involves calculating calibration factors using reference biometric values, but if the sensor's calibration parameters are unstable, it corrects the calculated factor instead of using it directly. The correction is based on the difference between the calculated factor and the previous factor. This allows accurate calibration even when sensor stability is changing. The correction is further refined by considering the section of sensor usage where the reference biometric was taken, as stability varies over time.

Source

Method for accurately estimating blood glucose levels using interstitial fluid glucose measurements. It involves a sensor to measure interstitial glucose levels, a Kalman filter to estimate blood glucose based on the sensor readings, and a state transition model to account for factors like diffusion. The method uses filtering, noise estimation, and outlier detection to improve accuracy. The state transition models adapt based on glucose rate changes.

Source

Filtering continuous glucose monitor (CGM) signals using a modified Kalman filter to improve accuracy and reduce downtime compared to conventional techniques. The filter adapts the noise covariance terms based on detected artifacts in the raw CGM signal. When artifacts like pressure or zero crossings are identified, the process and measurement noise covariances are updated. This allows the filter to better handle non-analyte related noise that can impact CGM performance.

Source

Reducing blanking of sensor glucose signals in continuous glucose monitoring (CGM) systems by using multiple machine learning models trained for specific conditions. The CGM device inputs sensor data into multiple models, each trained for different data characteristics or abnormal conditions. The models generate predicted glucose values. The device combines the predictions to generate the displayed glucose value. This improves accuracy and reduces blanking compared to using a single model.

Source

Calibrating a handheld diabetes managing device to accurately determine interstitial glucose levels from a continuous glucose monitor (CGM) without needing separate blood glucose measurements. The method involves subtracting the time-dependent zero-signal level of the CGM sensor from the continuous sensor signal to compensate for baseline drift. This allows the CGM to provide accurate glucose readings without needing separate calibration using blood glucose measurements.

Source

Monitoring blood glucose levels using a continuous glucose sensor with improved noise reduction techniques. The sensor filtering uses a Kalman filter with adaptive noise covariance estimates based on innovation and residual signals. This allows better noise reduction without long filtering gaps. Artifact detection is also implemented to trigger noise covariance updates. The technique adapts the filter parameters in real-time based on signal characteristics to better track glucose levels with reduced error.

Source

Adjusting blood glucose algorithms in a continuous glucose monitoring (CGM) system using motion sensors to provide more accurate glucose readings and alerts based on patient activity levels. The CGM system with motion sensors detects activity like sleeping or exercising. It then adjusts the glucose algorithms to account for the activity-related glucose fluctuations. For example, it recalculates low glucose alerts for sleeping patients to prevent false alarms.

Source

Improving continuous glucose monitoring (CGM) systems by using multiple machine learning models trained for specific conditions to generate more reliable sensor glucose values. The models are trained separately for factors like sensor data availability, accuracy, and probabilistic reliance. During CGM, the models are applied and outputs averaged to generate the sensor glucose value. For outlier conditions, signatures in sensor data are identified and models adjusted to prioritize those associated with the signature. This allows customization of models for situations like limited data or high variability to improve accuracy.

Source

Improving the accuracy and reliability of continuous glucose monitoring (CGM) systems by using machine learning to detect and correct errors in complex sensor data in real time. The system trains a machine learning model to identify outlier measurements based on sensor data behavior signatures informed by criteria like iCGM. If an outlier is detected, the sensor data is blanked or not displayed. The system also trains a model to identify erroneous sensor use conditions based on error patterns. The model determines resolutions to correct the errors.

Source

Improving the reliability of continuous glucose monitoring (CGM) devices, particularly for detecting the presence of acetaminophen medication and correcting the sensor glucose value. The method involves activating a glucose oxidase (GOx) electrode and a non-GOx electrode on the user. They are set to different voltages and signals are compared to detect acetaminophen ingestion. If acetaminophen is detected, the sensor glucose value is adjusted using a predetermined model. This allows for reducing finger sticks for calibration and improving CGM reliability by compensating for medication interference.

Source

Glucose sensing device that reduces the effect of noise in measuring glucose concentration. The device has a unique sensing method to minimize noise compared to conventional glucose sensors. The device generates a sensing pulse signal using just the current from the second sensing state when the voltage is different from the reference voltage. This pure current is used to generate the sensing pulse width, which is then compared to a reference pulse width to generate digital measurement data. Subtracting the noise current in the first state reduces noise in the final measurement.

Source

Redundant glucose sensing and disease management system that provides continuous monitoring when one sensor is in warmup, stabilization, or end-of-life periods. Multiple glucose sensors and insulin pumps attach to a patient simultaneously and communicate with each other. If a sensor goes offline, another sensor takes over. This ensures continuous glucose monitoring for closed-loop insulin administration systems even if a sensor fails.

Source

Improving accuracy of continuous glucose monitoring (CGM) devices by using short-term prediction to reduce random noise and calibration errors. The method involves substituting the current CGM reading with a predicted glucose value a short horizon ahead. This compensates for delays in the BG-to-IG kinetics and improves accuracy, especially at hypoglycemic levels. A Kalman filter is used for the prediction.

Source

Real-time detection of declining sensitivity in continuous glucose monitors (CGMs) to improve accuracy and prevent false alarms. The detection involves estimating the probability of sensitivity decline based on current sensor signals, and confirming if a threshold is exceeded using a single blood glucose measurement. This allows accurate detection of declining sensitivity without false positives.

Source

Method to accurately determine blood glucose levels using a continuous glucose monitoring (CGM) system by leveraging the moving horizon estimation (MHE) technique. The method involves continuously measuring interstitial glucose levels using a sensor and applying MHE to estimate the blood glucose based on the interstitial measurements. This takes into account the time delay and diffusion between blood and interstitial glucose levels. The MHE allows adaptive estimation of noise variances and model parameters over time for improved accuracy compared to Kalman filtering or smoothing the interstitial signals.

Source

Blood glucose measuring device that adaptively adjusts calibration intervals to minimize pain and errors. The device compares glucose readings from the sensor versus blood to calculate sensor error. It then determines how long it takes for that error to reach a threshold, using the initial calibration interval. The device then sets the calibration interval based on that time, allowing more frequent calibration if sensor error is high. This allows personalized calibration intervals based on sensor performance.

Source

Communication protocol for data communication between a continuous glucose monitoring transmitter and receiver. It involves generating a radio frequency (RF) data stream based on the monitored glucose data using a low-power, low-noise logic circuit consisting of finite-state machines and digital circuits. This avoids a high-power ASIC and enables accurate glucose monitoring for diabetes treatment. The transmitter sends glucose data in a synchronized window over RF to the receiver, which identifies the transmitter and displays the glucose levels.

Source

Monitoring the reliability of a glucose sensor used in closed-loop insulin pumps to determine when to switch to manual or open-loop operation. The reliability is assessed based on trends in the sensor data. If the trends indicate reduced sensitivity, anomalies, drift, or noise, it indicates the sensor is less reliable. A metric representing the reliability is calculated based on these trends. If the metric falls below a threshold, it triggers a switch to manual or open-loop operation to prevent relying on potentially inaccurate sensor readings for closed-loop insulin delivery.

Source
