Ink Removal for Fiber Recovery from Packages

Method for accurately aligning dynamic prints on packaging materials with static prints. The method involves removing the static print in predefined sections to reveal the underlying packaging material, creating a negative of the dynamic print inside the static print. A camera detects reference geometries from the static print and the manufactured negative to evaluate quality features like alignment and readability. This ensures proper positioning of dynamic prints despite packaging material variations.

Source

Pill packaging inspection system that automatically detects and removes defective pills during packaging to prevent damaged pills from reaching consumers. The system has a pill supply unit, transfer unit, inspection unit, and packaging department. The labeling inspection device in the packaging department checks for printing defects on the pill packaging labels. If defects are found, it stops packaging and separates the faulty packs. The device can detect issues like typo errors, number omissions/additions, and label position swaps.

Source

Two-component curing adhesive for laminates that exhibits releasability when immersed in an alkaline aqueous solution while maintaining adhesion. The adhesive has an isocyanate composition containing an polyisocyanate compound and an isocyanate-reactive composition with an active hydrogen group-containing compound. The active hydrogen compound has an average functional number of hydroxyl groups of 1.5-3.0 and acid groups of 0.2-2.0. This adhesive allows easy separation of laminated materials like packaging by immersion in alkali compared to conventional adhesives.

Source

Packaging material for shipping items that allows easy removal of personal information like sender and destination addresses to prevent identity leakage when the packaging is discarded. The packaging has a corrugated sheet with a flat sheet attached to the corrugated ridges. The flat sheet has a personal information display area surrounded by a cut-out frame. This frame allows the personal info area to be easily peeled off the flat sheet and corrugated sheet. The cut-out frame can be perforations or a partial cut that doesn't penetrate the flat sheet.

Source

A PET bottle processing device that simultaneously separates accessories from the bottle body and cleans the bottles. The device has two rotating shafts inside a case with radial protruding blade members. The shafts rotate out of phase to peel labels, caps, and release contents. Water showers the bottles while they're being processed. The blades transport the bodies to an upper discharge and washwater carries accessories to a lower discharge. This integrated cleaning and separation reduces processing time and device size compared to separate steps.

Source

Automated label removal device for glass jars that eliminates the need for chemicals and prevents jar damage. The device uses a conveyor, cameras, spray nozzles, vibrating trays, grippers, robotic arms, and air blowers. Jars are placed on the conveyor and imaged. Cleaning solution and oil are sprayed. Jars are vibrated with baking soda. Grippers transfer jars to a wiping platform. Robotic arms remove labels. Hot air blows jars clean. The conveyor moves jars to collection.

Source

A label for PET bottles that can be easily removed without leaving adhesive residue on the bottle. The label is a pressure-sensitive adhesive strip label coated with a fast drying adhesive. This allows the label to be easily peeled off the PET bottle without leaving adhesive behind. The fast drying adhesive prevents residue compared to slow drying adhesives. The label can be made using non-shrinking film or shrinkable film as the label material. This improves recyclability of PET bottles by preventing adhesive contamination during recycling.

Source

Label for PET bottles like water bottles that can be easily removed without leaving adhesive residue on the bottle after label removal. The label is coated with a pressure sensitive adhesive instead of the conventional slow drying adhesive. This allows the label to be easily peeled off without sticking to the PET bottle. This prevents adhesive residue on the bottle that can cause issues in recycling. The pressure sensitive adhesive is applied to the label before attaching it to the PET bottle.

Source

A label for PET bottles like water bottles that can be easily removed without leaving adhesive residue on the bottle surface. The label uses a pressure sensitive adhesive coating on the label instead of the conventional slow-drying adhesives. This allows the label to be easily peeled off without residue when removed. It solves the problem of adhesive residue in PET bottle recycling by using a label that can be completely separated and reuses the PET bottle without contamination. The label can be made with non-shrinkable or shrinkable film, depending on the bottle shape. The pressure sensitive adhesive allows easy label removal without residue, improving PET bottle recycling yield and quality.

Source

A storage base and packaging box design that enables easy and clean removal of the sealing film without leaving residue or damaging the contents. The storage base has a sealing part around the opening that fits with the sealing film. The sealing part has an arc-shaped guide edge connecting the fitting surface. This edge has a minimum radius of 0.15 mm. This design allows the sealing film to tear off cleanly from the base. The arc-shaped guide edge provides a defined path for the film to follow during removal, preventing it from sticking or separating.

Source

A label remover and storage device for plastic bottles that automates label removal and storage inside a rabbit-shaped container. The device has a label cutter inside the rabbit's mouth, an automatic label roller and storage inside the rabbit body, and a bottle cap opener shaped like the rabbit's exterior. This allows easy label removal without manual intervention and full automation of label storage in the rabbit-shaped container.

Source

Recycling system for transparent PET bottles that allows only pure PET resin particles to be extracted for recycling. The system is installed in common facility recycling points. It involves washing, crushing, screening, drying, and collection steps. Bottles with labels removed go through washing, then crushing to shreds. Screening removes impurities. Drying removes moisture. The pure PET particles can then be collected for recycling. This prevents contamination from adhesives and labels, making the recycled PET more valuable.

Source

A packaging box for containing items like medicines, cosmetics, etc. that allows displaying item descriptions without separate documents. The box has a removable lid section that peels off along break lines. Inside surfaces of the lid and an adjacent header piece can display item explanations. This provides visible item info without needing separate inserts or labels. The lid peeling feature prevents rubbing/obscuring during transport. The box also has side breaks for easy lid removal.

Source

Manufacturing a laminated fabric that is easy to separate from household containers and PET bottles. The manufacturing includes a printed material in an untreated cloth, a laminated fabric in an untreated cloth, and a guide molding in a form that prevents parallel ruptures by strongly pressing the fabric tissue (cell) to prevent parallel ruptures.

Source

A method for manufacturing a package with a notch using UV laser. The packaging material contains an intermediate layer with titanium dioxide. When the material is irradiated with UV laser, it transforms some of the titanium dioxide into rutile-type titanium dioxide. This discolored area absorbs more UV laser and generates heat. The surrounding packaging material is removed, forming a notch that reaches up to the surface. The UV laser power is 1-100 watts and wavelength is 250-400 nm.

Source

A biaxially oriented polypropylene (BOPP) film with structural color properties without the need for ink printing. The film has a base BOPP layer and an additional structural color layer on top. The structural color layer is made by coating a composite material containing metallic nanoparticles, organic dyes, and a binder on the BOPP surface. The composite material forms a thin film with structural color properties when viewed at certain angles due to light interference. This allows the film to have color-shifting effects without the need for ink printing, providing a more environmentally friendly and cost-effective alternative to traditional BOPP films with printed colors.

Source

A PET bottle crushing device that separates and removes labels and retainer rings from PET bottles before crushing to enable recycling. The device uses image recognition to detect if a label is present on a inserted bottle. If so, it discharges the bottle without crushing. If not, it crushes the bottle. A cutting blade removes the retainer ring if present. This allows recycling of labeled PET bottles without foreign substances and enables crushing of bottles with intact retainer rings.

Source

Washable labels for reusable packaging that can be easily removed without residue when washed. The labels have a discontinuous pattern on the adhesive side created by applying a spacer above the adhesive. This prevents complete adhesion in some areas, making it easier to wash off the label when the packaging is cleaned. The spacer thickness is optimized to balance adhesion and washability.

Source

A non-adhesive label installation structure for recyclable containers that allows easy separation and recycling without adhesive residue. The structure uses a molded container with a central pillar protruding from the bottom. The label attaches to support protrusions on the pillar instead of adhesive. This allows easy removal of the label without residue. The container also has stacking protrusions on the bottom and through holes in the lid to prevent container collapse during stacking.

Source

Disposable bottle design that simplifies recycling by allowing easy removal of the wrapping paper and adhesive without separate processing. The bottle has a scraper integrated into the lid that separates the wrapping paper from the main body when the lid is rotated. This automatically removes the wrapping paper after use, preventing residue and adhesive on the bottle. The scraper can be made of plastic or metal and extends below the wrapping paper to separate it.
