Voltage and Current Monitoring Systems for EV Batteries
Modern EV battery packs contain thousands of cells operating at voltages up to 800V and currents exceeding 500A, with individual cell monitoring requirements down to millivolt precision. These systems must maintain measurement accuracy across temperature ranges from -40°C to 85°C while detecting subtle voltage signatures that can indicate imminent thermal events.
The fundamental challenge lies in achieving precise, high-speed monitoring of numerous cells while maintaining signal integrity across harsh automotive environments and electromagnetic interference.
This page brings together solutions from recent research—including temperature-regulated current shunts, voltage rebound detection systems, ranking-based cell imbalance monitoring, and wavelet-based thermal event prediction. These and other approaches focus on early detection of potential failures while maintaining measurement accuracy during normal operation.
1. Battery Pack Connection Diagnostic System Utilizing Current, Voltage, and Resistance Measurements
LG ENERGY SOLUTION LTD, 2025
Diagnosing connection issues in battery packs and wiring to improve reliability and reduce failures in electric vehicles. The diagnosis involves measuring current, voltages, and resistance of the battery pack, bus bar, and wires. By analyzing these parameters, the connection status of the bus bar and wires can be determined. This allows detecting issues like loose connections, short circuits, or broken wires that may not be evident from just monitoring the bus bar alone.
2. Stacked Electrode Assembly with Integrated In-Stack Voltage Sensing Leads and Reference Electrode
GM GLOBAL TECHNOLOGY OPERATIONS LLC, 2025
Stacked electrode assembly with in-stack sensors for lithium-class batteries like Li-ion cells in vehicles. The assembly has working electrodes (anodes and cathodes) separated by insulating separators. Sensing leads on the separators contact specific regions of electrodes to measure voltage. A reference electrode connected to the leads provides signals to external sensing devices. This allows distributed electrode voltage mapping inside the stack without contacting individual cells.
3. Battery Rack Failure Detection System with Voltage and Temperature Trend Analysis
DELTA ELECTRONICS INC, 2025
A failure detection method and system for battery racks that can predict and prevent overvoltage issues in battery packs. The method involves monitoring voltage and temperature data from the battery racks over time. It checks for spikes in voltage variability, computes trends and slopes, and synthetically evaluates voltage trend changes to detect potential overvoltage precursors. This allows anticipating overvoltage conditions before they cause failure.
4. Rechargeable Battery State of Health Estimation via Current and Voltage Measurement and Generalized Fluctuation-Dissipation Theorem Application
HEI, 2025
Estimating the state of health (SOH) of a rechargeable battery using a method that involves measuring current and voltage during charging, applying the Generalized Fluctuation-Dissipation Theorem (GFDT) to obtain battery response functions, deriving SOH parameters from those functions, and tracking changes in the SOH parameters with charge capacity to estimate SOH. This allows estimating and predicting battery health without additional equipment beyond what is already used for charging.
5. Battery Module with Sensing Block for Insulation Resistance Monitoring of Individual Cell Pouches
HYUNDAI MOTOR CO, KIA CORP, 2025
Battery module with internal monitoring to check insulation of individual cells during manufacturing and after installation in electric vehicles. The module has a sensing block with an interface module to connect and measure voltage between the cell electrode tabs and pouch cut ends. This allows monitoring the insulation resistance of each cell pouch for quality control during manufacturing and detection of pouch corrosion or damage in installed batteries.
6. Coordinated Control of Photovoltaic Resources and Electric Vehicles in a Power Distribution System to Balance Technical, Environmental, and Energy Justice Objectives
abdulrahman almazroui, salman mohagheghi - Multidisciplinary Digital Publishing Institute, 2025
Recent advancements in photovoltaic (PV) and battery technologies, combined with improvements power electronic converters, have accelerated the adoption of rooftop PV systems electric vehicles (EVs) distribution networks, while these technologies offer economic environmental benefits support transition to sustainable energy systems, they also introduce operational challenges, including voltage fluctuations, increased system losses, regulation issues under high penetration levels. Traditional Voltage Var Control (VVC) strategies, which rely on substation on-load tap changers, regulators, shunt capacitors, are insufficient fully manage challenges. This study proposes a novel Voltage, Var, Watt (VVWC) framework that coordinates operation EV resources, conventional devices, demand responsive loads. A mixed-integer nonlinear multi-objective optimization model is developed, applying Chebyshev goal programming approach balance objectives include minimizing curtailment, reducing flattening profile, not met. Unserved has, particular, been modeled incorporating concepts distributional recognit... Read More
7. Battery Monitoring System (BMS) Using Arduino UNO
banoth srinu - Indospace Publications, 2025
Abstract - A Battery Monitoring System (BMS) is an electronic setup designed to track essential parameters of rechargeable batteries, such as voltage, current, and State-of-Charge (SoC). By preventing overcharging over-discharging, systems help extend the lifespan reliability batteries. However, commercially available BMoS solutions are often costly unsuitable for budget-friendly embedded systems. Given widespread use Arduino Uno its affordability, open-source platform, user-friendly programming environment, this study aims develop a using microcontroller. The proposed system includes voltage current sensors, board, liquid crystal display (LCD) real-time monitoring. To achieve this, set out three primary objectives. First, it was necessary mathematically establish relationship between sensors' input output values. These mathematical expressions were then validated by observing sensor outputs under varying load conditions connecting disconnecting monitoring corresponding readings. Following complete prototype assembled integrating sensors LCD with Uno. tested 11.1 V Lithium-ion ba... Read More
8. Bus Bar System with Integrated Temperature and Voltage Measuring Apparatus
VOLVO CAR CORP, 2025
Apparatus, bus bar system, and method for accurately measuring electrical parameters of a bus bar in vehicles. The apparatus has two measuring systems attached to the bus bar - one for temperature and one for voltage. The readings are sent to an interface that combines them to determine electrical parameters like current, resistance, and power factor without needing a separate shunt resistor or temperature sensor. This provides more robust and precise measurements compared to traditional methods.
9. Voltage Detection Circuit with Bleeder Resistance Network and Dual Comparator-Switch Configuration for Battery Packs
ABLIC INC, 2025
Voltage detection circuit for battery packs that provides improved overcharge and low voltage detection accuracy even in cases of cell balance disruption. The circuit divides the battery voltage into two divided voltages using a bleeder resistance network. An overcharge comparator and switch monitor the first divided voltage. A low voltage comparator monitors the second divided voltage. A first low voltage switch is closed when the battery is fully charged and open when discharged, while a second low voltage switch is open when fully charged and closed when discharged. This configuration allows accurate overcharge and low voltage detection regardless of cell balance.
10. Synchronous Sampling Circuits for Multi-Channel Monitoring in Battery Management Systems
SILERGY SEMICONDUCTOR TECHNOLOGY LTD, 2025
Synchronous monitoring circuits and methods for battery management in electric vehicles and energy storage systems that provide reliable voltage, current, and temperature monitoring with high accuracy and reliability in harsh operating environments. The circuits use synchronous sampling techniques to mitigate noise issues and improve accuracy compared to single-channel ADC sampling. The synchronous sampling involves coordinating the sampling of multiple channels using a common clock signal to avoid timing misalignment and noise coupling. This provides more accurate and reliable data for battery management applications.
11. An Enhanced Cascaded Deep Learning Framework for Multi-Cell Voltage Forecasting and State of Charge Estimation in Electric Vehicle Batteries Using LSTM Networks
supavee pourbunthidkul, narawit pahaisuk, popphon laon - Multidisciplinary Digital Publishing Institute, 2025
Enhanced Battery Management Systems (BMS) are essential for improving operational efficacy and safety within Electric Vehicles (EVs), especially in tropical climates where traditional systems encounter considerable performance constraints. This research introduces a novel two-tiered deep learning framework that utilizes two-stage Long Short-Term Memory (LSTM) precise prediction of battery voltage SoC. The first tier employs LSTM-1 forecasts individual cell voltages across full-scale 120-cell Lithium Iron Phosphate (LFP) pack using multivariate time-series data, including history, vehicle speed, current, temperature, load metrics, derived from dynamometer testing. Experiments simulate real-world urban driving, with speeds 6 km/h to 40 variations 0, 10, 20%. second uses LSTM-2 SoC estimation, designed handle temperature-dependent fluctuations high-temperature environments. cascade design allows the system capture complex temporal inter-cell dependencies, making it effective under variable-load Empirical validation demonstrates 15% improvement estimation accuracy over methods driving co... Read More
12. Battery Cell with Integrated Voltage Sensing via Internal Conductive Element in Sealed Pouch Design
GM GLOBAL TECHNOLOGY OPERATIONS LLC, 2025
Battery cell design with integrated voltage sensing to simplify stack monitoring while reducing contact between the cells and external sensors. The cells have internal energy storage elements surrounded by sealed pouches. A conductive element inside the pouch connects the cathode terminal to a sensor terminal on the same side. This allows voltage sensing of the cathode without external contacts on the cell. The conductive element can be a wire or metallic layer piercing the pouch.
13. IOT Based Smart Electric Vehicle
sachin badgire - International Journal for Research in Applied Science and Engineering Technology (IJRASET), 2025
This project introduces a smart electric vehicle (EV) system designed to make transportation cleaner, safer, and more efficient. It combines two ways of charging the using solar power traditional grid so that it can always stay powered, even if one source is unavailable. At heart an advanced Battery Management System (BMS) keeps battery healthy by monitoring its charge levels, balancing across cells, preventing damage. To ensure safety, also has thermal track temperature in real-time. If senses any risk overheating, take preventive action. All this data health, status, sent cloud IoT (Internet Things) technology, be monitored remotely from anywhere. setup helps maintaining vehicle, predicting issues before they happen, ensuring runs efficiently. By combining clean energy, monitoring, automation, aims support eco-friendly while improving safety Performance
14. Battery Management System with Modulated Signal Transmission Over Power Cables for Individual Cell Monitoring and Control
MONFORT TECHNOLOGY LLC, 2025
Battery management system that allows individual monitoring and control of battery cells without a complex web of wires. The system uses existing power cables between cells to transmit battery parameters and commands. A monitoring board on each cell monitors status and sends parameters to a central controller. The controller adjusts cell performance based on received data. This eliminates the need for extra wiring between cells and allows individual cell monitoring without grouping them into modules. The data is transmitted by injecting modulated signals onto the existing power cables.
15. Open Circuit Voltage Estimation Method for Chargeable Batteries Using Voltage Fitting and Threshold-Based Voltage Discarding
FURUKAWA AUTOMOTIVE SYSTEMS INC, FURUKAWA ELECTRIC CO LTD, 2025
A method to accurately estimate the open circuit voltage of a chargeable battery regardless of dark current. The method involves measuring battery voltage and current, storing voltage values after charge/discharge, fitting a function to the stored voltages, calculating open circuit voltage using the fitted function, and discarding stored voltages if current or voltage fluctuates above a threshold. This prevents unreliable voltages due to current fluctuations from impacting the open circuit voltage estimation.
16. Modeling and analysis of three-phase boost rectifier for DC fast EV charging
jeerapong srivichai, kittaya somsai, n pornsuwancharoen - Institute of Advanced Engineering and Science (IAES), 2025
This research investigates the modeling and analysis of a three-phase boost rectifier for DC fast charging systems electric vehicles (EVs). A mathematical model validated with MATLAB/Simulink simulations examines system behavior under various conditions. Performance in abc dq coordinate reveals high consistency theoretical calculations. The average voltage frame was found to be vd 685 V vq 0 V, discrepancy less than 0.1% from calculated values. However, current showed discrepancies due cross-coupling effects circuit impedance. Simulations reported id 211.50 iq 93.50 A, compared values 151.97 V. For output current, were 983.05 98.31 respectively. Three test cases analyzed, consist unbalanced conditions, drops, load step responses. Case 1 highest total harmonic distortion (THD), 2 increased THD further, 3 achieved lowest THD, demonstrating improved stability dynamic loads. These findings confirm systems minimal deviations predictions, enhanced quality, mitigation, efficiency EV applications.
17. Sensors Innovations for Smart Lithium-Based Batteries: Advancements, Opportunities, and Potential Challenges
jamile mohammadi moradian, amjad ali, xuehua yan - Springer Science+Business Media, 2025
Abstract Lithium-based batteries (LiBs) are integral components in operating electric vehicles to renewable energy systems and portable electronic devices, thanks their unparalleled density, minimal self-discharge rates, favorable cycle life. However, the inherent safety risks performance degradation of LiB over time impose continuous monitoring facilitated by sophisticated battery management (BMS). This review comprehensively analyzes current state sensor technologies for smart LiBs, focusing on advancements, opportunities, potential challenges. Sensors classified into two primary groups based application: optimization. Safety sensors, including temperature, pressure, strain, gas, acoustic, magnetic focus detecting conditions that could lead hazardous situations. Performance optimization such as optical-based electrochemical-based, monitor factors charge health, emphasizing operational efficiency lifespan. The also highlights importance integrating these sensors with advanced algorithms control approaches optimize charging discharge cycles. Potential advancements driven nanotechnolo... Read More
18. Intelligent Battery Management in a Hybrid Photovoltaic Using Fuzzy Logic System
joann v magsumbol, argel a bandala, alvin b culaba - Multidisciplinary Digital Publishing Institute, 2025
LiFePO4 batteries need a battery management system (BMS) to improve performance, extend their lifespan, and maintain safety by utilizing advanced monitoring, control, optimization techniques. This paper presents the design, development, implementation of an intelligent (i-BMS) that integrates real-time monitoring control batteries. The was extensively tested using multiple datasets, results show able temperature within set range, balance cell voltages, distribute energy according load prioritization. It uses fuzzy logic approach effectively manage farm requirements. Additionally, proposed method embedded three-level prioritization algorithm woven into rule allocate dynamically among essential, regular, non-essential loads.
19. IoT-Based BMS for Remote Battery Health Monitoring and Optimization
g shasikala, n nayana, n thameem, 2025
This project presents the development of an IoT-based Battery Management System (BMS) utilizing Random Forest Regressor machine learning model for remote battery health monitoring and optimization. The system integrates IoT-enabled sensors to collect real-time parameters such as voltage, current, temperature. data is transmitted through secure IoT gateways a cloud platform processing. employed predict critical metrics, including capacity degradation remaining useful life. enhances predictive accuracy enables informed decision-making optimized usage, thereby improving efficiency longevity. innovative solution demonstrates potential combining revolutionize management foster sustainable energy solutions.
20. Multiband Multisine Excitation Signal for Online Impedance Spectroscopy of Battery Cells
roberta ramilli, nicola lowenthal, marco crescentini - Multidisciplinary Digital Publishing Institute, 2025
Multisine electrochemical impedance spectroscopy (EIS) represents a highly promising technique for the online characterization of battery functional states, offering potential to monitor, in real-time, key degradation phenomena such as aging, internal resistance variation, and state health (SoH) evolution. However, its widespread adoption embedded systems is currently limited by need balance measurement accuracy with strict energy constraints requirement short acquisition times. This work proposes novel broadband EIS approach based on multiband multisine excitation strategy which signal spectrum divided into multiple sub-bands that are sequentially explored. enables available be concentrated portion at time, thereby significantly improving signal-to-noise ratio (SNR) without substantially increasing total time. The result more energy-efficient method maintains high diagnostic precision. We further investigated optimal design these sequences, taking account realistic imposed sensing hardware limitations amplitude noise level. effectiveness proposed was demonstrated within comprehensiv... Read More
